Our KARA range. A 19% chromium Ferritic Stainless Steel stabilised with molybdenum and niobiumthat offers elevated hot mechanical properties and a resistance to high temperature oxidation and creep (up to 1050°C).

Main features

Good weldability; ease of forming; good resistance to corrosion (in gas boiler and burner environments) and high temperature oxidation and creep (up to 1050°C); enhanced hot mechanical properties (without risk of σ phase formation at intermediate temperatures); greater thermal conductivity and lower expansion coefficient than austenitic grades.

Applications

  • Domestic boilers burners
  • Catering burners
  • Furnaces
  • Industrial boilers components
  • Fuel cells
K44M – 1.4521

Norms

  • ASTM 444
  • UNS S44400
  • EN 1.4521
  • IMDS ID 336853368

Chemical Composition

Typical values

  • C=0.015
  • Si=0.40
  • Mn=0.30
  • Cr=19.00
  • N=0.015
  • Nb=0.60

Alphanumerical designation X2CrMoTi18-2

Dimensional range

Coils

  • Thickness: from 0.40 to 3 mm
  • Width: up to 1,524 mm

Sheets, Blanks

  • Thickness: from 0.50 to 5 mm
  • Width: up to 1,250 mm

Discs

  • Thickness: from 0.38 to 2.50 mm
  • Diameter: from 15 to 1,000 mm

Surface aspects

  • Cold rolled
  • 2B, 2D, 2R

According to thickness.
