DX2304 – 1.4362

DX2304 – 1.4362

DX2304 – 1.4362

This Duplex grade offers excellent corrosion resistance and improved mechanical strength.

Main features

Excellent resistance to general corrosion (similar to 316L), improved mechanical strength (yield strength twice as that of 304/316 grades), possibility to save weight in properly designed applications, service temperature range of -50°C to 300°C, improved stress corrosion resistance compared to 304/316 grades.

Applications

  • Desalination systems
  • Construction: façade & footbridges
  • Flexible tubes
  • Oil & Gas industry
  • Mining
  • Pulp & paper industry
  • Pressure vessels
  • Caustic solutions
  • Organic acids
  • Safety panels
DX2304 – 1.4362

Norms

  • ASTM 23-04
  • UNS S32304
  • EN 1.4362
  • IMDS ID 336853946

Chemical Composition

Typical values

  • C=0.02
  • Mn=1.80
  • Cr=22.80
  • Mo=0.40
  • Ni=3.80
  • N=0.13

Alphanumerical designation X2CrNiN23-4

Dimensional range

Coils & Sheets

  • Thickness: starting from 0.8 mm and up to 10 mm
  • Width: up to 2,000 mm (according to thickness)

Discs

  • Please consult us

Surface aspects

  • Hot rolled & Cold rolled

According to forms & dimensions.

Download

Whether you need a certificate or more information, you can download all our product brochures, specifications, e-books, and related materials here.
DX2304 (1.4362)
E-Book - Duplex
